PoE20-SPA
- Model:PoE20-SPA
- Power:20W
- Output voltage:50V
- Output current:0.01-0.36A
- Download: Click there to view details.
Wechat: |
Features
Meets IEEE802.3 af standard
Compatible for 10/100 Mbps data transmission
With a built-in network conversion connector
Meets energy star level VI & CoC V5 Tier 2(2016)
Electrial Specifications
Input Voltage Range: 90 ~ 264VAC
Input Current Range: 500mA
Output Voltage Range: ±5%
MTBF: 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217
Standby Power: 0.055W
Environmental Parameter
Operation Temp: - 10℃ ~ 40℃
Storage Temp: - 20℃ ~ 70℃
Humidity : 5% to 93% non condenising
Dimensions
115mm (L) ; 40.3mm (W) ; 31mm (H)
Applications
IP Phone,Wireless AP, Portable Charger, POS device
Output data
Model |
Voltage |
Current |
Ripple |
Av. Eff. | |
115 230 | |||||
PoE20-S500036SPA | 50.0 | 0.01-0.36 | 200 | Y Y | 85.45 |
