Your position： Home > Products > Medical power supply

UES30-SPA-OP

Model：
Power：30W
Output voltage：5.00-48.00V
Output current：0.01-6.0A
Download： Click there to view details.

0769-21685502 / 13926846002

Wechat:

Consult Now

Details Recommend

產品特性醫療和I.T.E.安全認證 2 MOPP 隔離保護 漏電流 ≤ 100μA DOE 六級能效待機功耗≤0.075W 工作海撥高度5000米電氣規格輸入電壓:90~264VAC 輸入電流:1.0A at 115vac 環境參數 工作溫度: -10~50℃ 儲存溫度: -20~70℃ 工作濕度:10~90% 儲存濕度:5~90%

安規認證
安全機構/標志	醫療	通信
CB	IEC60601-1	IEC62368-1
NRTL	ANSI/AAMI ES60601-1 CAN/CSA C22.2 NO.60601-1	-
TUV-Mark	EN60601-1	EN62368-1

型號	電壓（伏）	電流 (安培)	額定功率	紋波 (最大) mVpk-pk	電壓公差	線性與負數調整率	平均效率	啟動延遲時間
	5.0	0.01-6.0	30W	120	±5%		86.0%	≤3s
	5.1-6.0	0.01-5.88	30W	120	±5%		86.0%	≤3s
	6.1-7.5	0.01-4.92	30W	120	±5%		87.7%	≤3s
	7.6-8.0	0.01-3.95	30W	120	±5%		87.7%	≤3s
	8.1-9.0	0.01-3.70	30W	120	±5%		87.7%	≤3s
	9.1-10.0	0.01-3.30	30W	120	±5%	線性調整率: ±1%	87.7%	≤3s
UES30-XXXYYYSPA -OP	10.1-11.0	0.01-2.97	30W	120	±5%	負載調整率: ±5%	87.7%	≤3s
	11.1-12.0	0.01-2.70	30W	120	±5%		87.7%	≤3s
	12.1-13.0	0.01-2.48	30W	120	±5%		87.7%	≤3s
	13.1-14.0	0.01-2.29	30W	120	±5%		87.7%	≤3s
	14.1-15.0	0.01-2.13	30W	120	±5%		87.7%	≤3s
	15.1-16.0	0.01-1.99	30W	200	±5%		87.7%	≤3s
	16.1-17.0	0.01-1.86	30W	200	±5%		87.7%	≤3s
	17.1-18.0	0.01-1.75	30W	200	±5%		87.7%	≤3s
	18.1-19.0	0.01-1.66	30W	200	±5%		87.7%	≤3s
	19.1-20.0	0.01-1.57	30W	200	±5%		87.7%	≤3s
	20.1-21.0	0.01-1.49	30W	200	±5%		87.7%	≤3s
	21.0-22.0	0.01-1.42	30W	200	±5%		87.7%	≤3s
	22.1-23.0	0.01-1.36	30W	200	±5%		87.7%	≤3s
	23.1-24.0	0.01-1.30	30W	200	±5%		87.7%	≤3s
	24.1-27.0	0.01-1.24	30W	200	±5%		87.7%	≤3s
	27.1-30.0	0.01-1.11	30W	300	±5%		87.7%	≤3s
	30.1-33.0	0.01-1.00	30W	300	±5%		87.7%	≤3s
	33.1-36.0	0.01-0.91	30W	300	±5%		87.7%	≤3s
	36.1-39.0	0.01-0.83	30W	300	±5%		87.7%	≤3s
	39.1-42.0	0.01-0.77	30W	300	±5%		87.7%	≤3s
	42.1-45.0	0.01-0.71	30W	300	±5%		87.7%	≤3s
	45.1-48.0	0.01-0.67	30W	300	±5%		87.7%	≤3s
