Features
Wide range of AC input voltage 150-270VAC

Protections against: short circuit/over current/over voltage

Meets 4KV surge immunity

Meets energy star level V (V2.0)

Electrial Specifications

Input Voltage Range: 150-270VAC
Input Current: 500mA
Output Voltage Range: ±5%
Average Efficiency: Meets energy star level V (V2.0)
MTBF: 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217
Standby Power: 0.3W
Environmental Parameter
Operation Temp: -5℃ ～ 40℃
Storage Temp: - 40℃ ～ 70℃
Humidity : 5% to 95% non condenising
Saftey Standard
CCC(GB4943.1)

Dimensions

62.0mm (L) ; 29.0mm (W) ; 40.0mm (H)

Applications
ITE Equipment

Output data

Model	Voltage （V)	Current (A)	Ripple (mV)	115     230	Av. Eff.  (%)Min
UE12L6-120YYYSPAC	12.0	0.01-1.0	150	Y     Y	77.90

YYY: 001-100 Stands for current  0.01-1.00A
